www.advancedco.com
91
7.8.1 View Menu
MAIN MENU
[View Menu] User 1 Node 1
ALARMS OFF-NORMAL NETWORK
INPUTS OUTPUTS LOG PANEL
OFF-NORMAL SUB-MENU
[Off-Normal Menu] User 1 Node 1
ALARMS SUPERVISORY TROUBLE
DISABLED PRE-ALARM WARNING
PROBLEMS MNS-ALARM
Note: Alarm, MNS-Alarm and other Off-Normal conditions (Supervisory, Trouble, Pre-Alarm, Disabled and
Warning), with the exception of Problems, are all normally shown without having to select the view menu. If
however, you wish to manually view any of these, they can be selected from this menu as required.
Problems are specifically associated with device dirty (detectors) when utilizing the Advanced’ enhanced
calibration capabilities, these pre-dirty detector conditions can be view via the off-normal area, in addition
to being transmitted via email from an optional AX-LAN (ipGateway).
7.8.1.1 View - Network
This Option can be used to obtain “real time” diagnostic information when a network is used to connect other panels
or remote annunciators. The access level of all panels on the network can be checked from any display. Access
level determines what user functions can be performed from the specific display. Below is an example of View-
Network:
[NETWORK – Press 0 to Clear] More>
Node Status
1 LOCAL
2 AccLev 2
3 AccLev 1
4 -
Additional network diagnostics (i.e.: node answer-backs, packet evaluation, etc.) are available by selecting the
“More>” option.
View-Network:
[NETWORK – Press 0 to Clear]
Data Packets : xxxxx
Bad Packets : 0
Comms lost : 0
Next Node at : x
Pressing “0” allows the stored network status information to be cleared.
