Enter the required address (# = all intelligent detectors on that loop) using the number buttons and then press the
✔ button to confirm.
The panel will now read the extended memory locations for all intelligent detectors on the loop. When complete, the
display will present the information as follows:
[Loop 1 Devices] <More>
Address Additional Info
>001.0 EEP[ 1] = 23
002.0
003.0 EEP[ 1] = 21
004.0 EEP[ 1] = 22
Refer to the device data sheets for an explanation of the extended memory locations and for further information on
the expected values.
11.2 Loop Isolators
It is recommended that there are a maximum of 20 intelligent detectors and/or addressable devices between loop
isolators.
Note: Some devices (particularly modules) are specified as representing the equivalent of two or more
device loads.
For further information, refer to the device data sheet.
