4.18.1 AX-012 Panel Printer Programming
Refer to Printer Menu section of this manual.
4.19 AX-MDM 24 VDC Modem Module
The AX-MDM 24 VDC modem module provides remote telephone dial-in access to an AX-CTL-1L, AX-CTL-2 or
AX-CTL-4 intelligent fire alarm control panel’s AX-CTL base card. This access allows qualified/trained Advanced’
technicians’ remote access, through the Advanced Axis
AX
terminal dial-up program, to monitor, maintain and
perform service of a single Axis
AX
fire alarm control panel.
The AX-MDM can either mount onto the four (4) standoffs located on the left-hand side of the Axis
AX
enclosure
below the AX-CTL base card or within an AXM-009 enclosure.
Note: If an AX-RL8, AX-RL4, AV-AMP-80 or AX-CZM module is installed in the Axis
AX
Intelligent Fire Alarm
Control Panel an AX-MDM module cannot be added. However, the AX-MDM module can be mounted
remotely in an AXM-009 or AX-GCAB enclosure.
