Example of an unacknowledged alarm event:
NEW ALARM IN ZONE 0001
< New unacknowledged alarm message
First Floor
Front Lobby Exit [PULL STATION]
< Zone alarm text (32 Characters)
< Device text (26 Characters) & type of device
(Press → for device details)
.ALARMS: 1 MNS: 0 SUPERVISORY: 0..
< Further device details
< # Alarms, # MNS and # Supervisory events
Example of unacknowledged multiple alarms, MNS and supervisory events:
NEW ALARM IN ZONE 0001 (Scroll
↓
)
< 1st New alarm message, w/Scroll active
First Floor
Front Lobby Exit [PULL STATION]
< Zone alarm text (32 Characters)
< Device text (26 Characters) & type of device
(Press → for device details)
.ALARMS: 2 MNS: 1 SUPERVISORY: 1..
< Further device details
< # Alarms, # MNS and # Supervisory events
Pressing the “ACK” button will acknowledge the alarm condition(s). This changes the red Alarm LED to steady, the
internal buzzer silences, and the display will show “ALARM IN ZONE xxxx” (acknowledged event) with zone/device
messages for the specific device in alarm.
Note: The AX-CTL-1L, AX-CTL-2 and AX-CTL-4 intelligent fire alarm control panel acknowledges on a
“Global” basis; all active events are acknowledged with the single activation of the acknowledge button.
After acknowledgement the display will indicate the first alarm, and a tally of any additional alarms, mass notification
and supervisory events. To view additional alarm, mass notification and supervisory events the user must scroll
(Scroll ↓) through the display. Displayed events are based on system priority, and the order in which the panel
received the individual event (i.e.: alarms are listed before mass notification and supervisory, and each are labeled;
1st Alarm, 2nd Alarm, 3rd Alarm, 4th Alarm, 1st MNS, 2
nd
MNS, 1st Supervisory, 2nd Supervisory, etc.).
Note: The (Scroll ↓) feature is only active when multiple viewable events are present. When utilizing the
scroll buttons, if the buttons are not activated for approximately 15 seconds, the display will revert back to
the 1st Alarm message.
Example of acknowledged single alarm event:
ALARM IN ZONE 0001
< Acknowledged alarm message
First Floor
Front Lobby Exit [PULL STATION]
< Zone alarm text (32 Characters)
< Device text (26 Characters) / type of device
(Press → for device details)
.ALARMS: 2 MNS: 1 SUPERVISORY: 1..
< Further device details
< # Alarms # MNS and # Supervisory events
Example of acknowledged multiple alarm, MNS and supervisory events:
1st ALARM IN ZONE 0001 (Scroll
↓
)
< 1st alarm message, w/scroll active
First Floor
Front Lobby Exit [PULL STATION]
< Zone alarm text (32 Characters)
< Device text (26 Characters) / type of device
(Press → for device details)
.ALARMS: 2 MNS: 1 SUPERVISORY: 1..
< Further device details
< # Alarms # MNS and # Supervisory events
