Milling Machine Series
CNC operations
100
Advantech-LNC Technology Co., Ltd.
1.7.15 Project settings
Description of the project setting function:
In response to various industry demands, this system allows users to customize extra functions in addition to the
general functions, which can be executed in coordination with project settings.
Instructions for configuring project settings:
After using the <MAINTE> key on the MDI panel to switch to maintenance group, the 【 > 】 key can be pressed
to access the project settings page via the 【Project settings】 key.
Description of various fields:
1. Subproject folder: It is used for setting the subproject to be directly executed after machine startup. If
this field is set, the home page will directly jump to the subproject page after system startup. (0 to 6, 0:
None 1: open_mill_ext 2: open_ext_end_1 3: open_ext_end_2 4: open_op 5: open_tool_teach 6:
open_ccd)
If this field is set as 0, the subproject can be accessed by pressing the function key corresponding to the
folder name in which the subproject is placed.
2. Subproject - return to group key: It is for setting the key menu level which can be reached by pressing
the return key on the subproject's key menu. (-1 to 5, -1: self-defined for the project 0: Group key menu
1: Monitoring group 2: Program group 3: compensation group 4: Diagnosis group 5: Maintenance
group)
3. Hide group key menu: It is for setting whether users can return to the group key menu level by pressing
the return key. (0 to 1, 0: No 1: Yes)
