Advantech LNC M5800 Series User Manual

Milling Machine Series
CNC operations
76
Advantech-LNC Technology Co., Ltd.
 When any bit of IOCSA is selected, the bit function's description will be displayed in the message display section
located near the lower left corner of the screen.
1.6.4 Timer/counter
Description of the timer/counter function:
 When the timer/counter function is used by system startup, program execution, and the PLC, this page can be
used for inquiring and browsing current operating status of the timer/counter.
Instructions for using the timer/counter:
 After using the <DGNOS> key on the MDI panel to switch to diagnosis group, the 【Timer/counter】 key can be
pressed to access the timer/counter page.
 Viewers can change views by using the arrow keys on the MDI panel, or use the <PgUp> and <PgDn> keys for
quickly switching pages.
