Milling Machine Series
CNC operations
75
Advantech-LNC Technology Co., Ltd.
1.6.3 IOCSA
Description of the IOCSA function:
It is used to examine the system's I/O status and internal status.
The contact points at I, O, C, S, and A of the PLC represent machine functions corresponding to keys on the
machine. This page is for system designers and maintenance personnel, as well as for users to inquire and
browse the switching actions of contacts points I, O, C, S, and A.
Instructions for using IOCSA:
After using the <DGNOS> key on the MDI panel to switch to diagnosis group, the 【IOCSA】 key should be
pressed to access the IOCSA page.
Press the 【 I 】 key, 【 O 】 key, 【 C 】 key, 【 S 】 key, 【 A 】 key, 【 IO 】 key, 【 CS 】 key,
【IOCSA】 key, and then press the 【Find】 key to enter the number to be found in the input section, press
Confirm to switch to the position screen corresponding to that number.
