1.3 Monitoring group (MONITOR)
1.3.1 Monitoring
 On the monitoring page, users can view various information such as the filename of the current program,
current operating mode, current machine status, has an alert being issued, feeding % status, spindle % status,
number of workpieces undergoing the machining process, maximum number of machining pieces, time required
for single machining, total time of machining accumulated, and various coordinates.
Description of various fields:
 Users can inspect the current machining program's filename on the monitoring page as shown in the figure
below.
