Milling Machine Series
CNC operations
14
Advantech-LNC Technology Co., Ltd.
1: Path information. (It will only be shown when the multi-path function is available)
Note: numerator is the current path number, and denominator is the total number of paths.
2 : Name of currently assigned program.
Note: it refers to the filename currently being used by the controller.
3 : CNC mode information.
Note: 1. Jog, 2. Reference point, 3. Manual, 4. Incremental, 5. Hand wheel, 6. Automatic
4 : Machine's status information.
Note: 1. Not ready, 2. Ready, 3. Cycle start, 4. Machine paused, 5. Section stopped.
5 : Current function group.
Note: 1. Monitoring, 2. Program, 3. Offset, 4. Diagnosis, 5. Maintenance.
6 : Name of current page.
Note: it refers to the function page currently accessed by the controller.
7 : System time and user level.
Note: it refers to the current user level between L1 to L7.
8 : Range of each screen's display area.
Note: the range of variation to be shown by switching among function pages of each group.
9 : Input area/section.
Note: provided by the controller for users to input values in various fields on each page.
10: Summary information reminder section.
Note: the controller will provide an operation information summary prompt to remind users.
11: Display areas corresponding to the keys on the screen.
Note: this area is to be used for corresponding keys on the screen. If there are keys listed in this manual but they
cannot be seen on the controller, it means that current user does not have the proper permission level.
12: Error messages.
Note: Alerts and warnings.
