GPIB OPERATION
3-2-9
TABLE 3-2-1 INSTRUMENT DEFAULT SETTINGS (continued)
Modulations : FM1 : 0 Hz, Int F4, ON
FM2 : 0 Hz, Ext 1 ALC, ON
ΦM1 : 0 rad, Int F4, ON
ΦM2 : 0 rad, Ext 1 ALC, ON
AM1 : 0%, Int F4, ON
AM2 : 0%, Ext 2 ALC, ON
WBFM : (Minimum setting), AC coupled, ON
Steps : ΔFM 1 kHz, ΔΦM 0.1 rad, ΔAM 1%
Modulation source : IntF1 : 300 Hz sine
IntF2 : 400 Hz sine
IntF3 : 500 Hz sine
IntF4 : 1 kHz sine
IntF5 : 3 kHz sine
IntF6 : 6 kHz sine
Step : 1 kHz
LF Mode : Monitor, mod source
LF generator Frequency : 1 kHz sine, step 1 kHz
Level : 100 μV
Step : 1 dB
Status : ON
Sweep:
Type : RF level
Mode : Single internal
RF level sweep :
Start : −144 dBm
Stop : 10 dBm
Steps : 100
Time : 50 ms
Markers : 2, 4, 6, 8, 10 dBm, disabled
Carrier freq. sweep :
Start : 100 MHz
Stop : (Maximum available)
Steps : 250
Time : 50 ms
Markers : 200, 400, 600, 800, 1000 dBm, disabled
Mod. source freq. :
Start : 0.1 Hz
Stop : 500 kHz
Steps : 10,000
Time : 500 ms
Markers : 100, 20, 30, 400, 500 kHz
Sequential tones :
Mode : No modulation selected
Standard : CCIR
Sequence : 16 tone Fs
Duration : All normal
Frequency offset : 0
Extended duration : 500 ms
Repeat tone : E
Start delay : 200 ms
