Aeroflex 2030 Series User Manual

ACCEPTANCE TESTING
5-1-4
TEST PROCEDURES
Before each test, it is recommended that the UUT is reset to its switch-on conditions
which are as follows:
Carrier freq 1.35 GHz (2030), 2.7 GHz (2031), 5.4 GHz (2032)
RF level -144 dBm
FM 0 Hz ON
Single modulation mode
Modulation ENABLED
RF OUTPUT
SPECIFICATION
Level range: -127 dBm to +13 dBm (usable to -144 dBm)
Accuracy: (2030, 2031 and 2032)
±0.85 dB from 10 kHz to 1.35 GHz at levels >-127 dBm
±0.50 dB from 10 kHz to 1.35 GHz at levels >0 dBm
(2031 and 2032)
±1.0 dB from 1.35 GHz to 2.7 GHz at levels >-127 dBm
±0.7 dB from 1.35 GHz to 2.7 GHz at levels >0 dBm
(2032 only)
±1.5 dB from 2.7 GHz to 5.4 GHz at levels >-100 dBm
±1.5 dB from 2.7 GHz to 5.4 GHz at levels >-50 dBm
±1.0 dB from 2.7 GHz to 5.4 GHz at levels >0 dBm
TEST EQUIPMENT
Description Minimum specification Example
RF power meter ±0.1 dB from 30 kHz to 2.7 GHz IFR 6960B and 6910 or 6912
sensor
Measuring receiver 0 dBm to −127 dBm; 2.5 MHz to
1300 MHz
HP 8902A and 11722A
sensor and 11793A
down converter
Signal generator 8 dBm from 32.5 MHz to 5.4 GHz IFR 2032
