OPTION 008 RF PROFILES AND COMPLEX SWEEP
Annex-C-7
Carrier :
Freq.
RF Level : dBm
Single Modulation Mode Modulation ENABLED
MHz
Int Std: 10 MHzOffset: +20.0 dB
FM: Hz
Int F4: 1.0000 kHz
0
ON
100.000 0000
+0.0
ON
FM
Devn.
Source
Freq : F4
FM
ON/OFF
Select
Source
RF
Level
Carrier
Freq.
LOCAL
Low
Intermod
ΦM
AM
Wideband
FM
C0863
Fig. C-4 Main signal generator screen with RF offset enabled
RF PROFILES
If the [Profiles] key is selected from the menu shown in Fig. C-2 the display shown in
Fig. C-5 is displayed. But note that the [Save Setting] and [Edit Profile] keys will only appear if
the instrument is unlocked to Level 1.
Select
Profile
LOCAL
Enable/
Disable
Save
Setting
Edit
Profile
EXIT
RF Profile Menu
Profile Selected:
1-
Profile: DISABLED
C0865
Fig. C-5 RF profile menu (shown unlocked to Level 1)
Up to 10 profiles may be generated and stored using this facility. The profiles are
identified as Profile 0 to Profile 9. Each profile can have up to 100 frequencies at which the
output level of the signal generator can be adjusted by up to ±40 dB to compensate for the
frequency response of an external device without altering the displayed RF level of the signal
generator.
