Aeroflex 2030 Series User Manual

OPTION 008 RF PROFILES AND COMPLEX SWEEP
Annex-C-13
Selecting a sequence sweep
To enter the Sequence Sweep mode press the [SWEEP] key to obtain the main sweep
generator menu. If the last used sweep is not a sequenced sweep press [Sweep Type] to obtain
the display shown in Fig. C-11, press [Sweep Sequence] and use the [EXIT] or [SWEEP] key to
return to the Sweep Sequence selection menu shown in Fig. C-12.
Sequence
Sweep
LOCAL
RF Level
Sweep
Carrier
Sweep
Int. F4
Sweep
Sweep
OFF
EXIT
C0858
Sweep Type Menu
Current Sweep Type : SEQUENCE SWEEP
Fig. C-11 Sweep type menu
Note...
RF profiles cannot be applied to the normal carrier sweep provided on the generator. If
RF profiles are enabled the [Carrier Sweep] key in Fig. C-11 will not be displayed.
RF
Info.
LF
Info.
Sweep
Sequence
LOCAL
Start
Sweep
Modify
Segments
Sweep
Type
Sweep
Mode
Sweep Sequence:
Sweep Status: WAITING FOR TRIGGER
Sweep Mode: INTERNAL SINGLE
Sweep Type: SEQUENCE SWEEP
C0859
0 - - - - - - - - -
Fig. C-12 Sweep sequence selection menu
