Aeroflex 2030 Series User Manual

ACCEPTANCE TESTING
5-1-27
Table 5-1-18 Carrier sub-harmonic frequencies
UUT carrier
Spectrum analyzer frequency (Hz)
(2031/2)
1,350,100,000.0 675,050,000.0 2,025,150,000.0
1,500,000,000.0 750,000,000.0 2,250,000,000.0
2,000,000,000.0 1,000,000,000.0 3,000,000,000.0
2,299,999,990.0 1,149,999,995.0 3,449,999,985.0
2,300,000,010.0 1,150,000,005.0 3,450,000,015.0
2,649,000,000.0 1,324,500,000.0 3,973,500,000.0
2,700,000,000.0 1,350,000,000.0 4,050,000,000.0
fc
4
and
3fc
4
fc
2
and
5fc
4
(2032)
2,701,000,000.0 675,250,000.0 1,350,500,000.0
2,025,750,000.0 3,376,250,000.0
3,375,000,000.0 843,750,000.0 1,687,500,000.0
2,531,250,000.0 4,218,750,000.0
4,050,000,000.0 1,012,500,000.0 2,025,000,000.0
3,037,500,000.0 5,062,500,000.0
4,725,000,000.0 1,181,250,000.0 2,362,500,000.0
3,543,750,000.0 5,906,250,000.0
5,400,000,000.0 1,350,000,000.0 2,700,000,000.0
4,050,000,000.0 6,750,000,000.0
Non-harmonics
(1) Connect the test equipment as shown in Fig. 5-1-13.
(2) Set the UUT to [RF Level] 0 dBm [Carrier Freq.] 10 kHz.
(3) Set the spectrum analyzer to a span of 100 Hz, 10 Hz filter, and referring to
Table 5-1-19, measure the level of the non-harmonics at the frequencies indicated
ensuring that the levels measured are less than -70 dBc.
Table 5-1-19 Carrier non-harmonic frequencies
UUT carrier Spectrum analyzer frequency (Hz)
frequency (Hz)
(2030/1/2)
10,000.0 104,867,600.0
1,000,000.0 105,857,600.0
20,000,000.0 124,857,600.0
21,093,749.0 125,951,349.0
200,000,000.0 104,867,600.0
1,350,000,000.0 1,348,322,280.0 & 1,351,677,720.0
(2031/2)
2,700,000,000.0 2,500,000,000.0
(2032)
5,400,000,000.0 5,200,000,000.0
