GENERAL INFORMATION
1-8
Accuracy At 22 ±5 °C ambient:
Carrier frequency range
Output level 10 kHz
to
1.35 GHz
1.35 GHz
to
2.7 GHz
2.7 GHz
to
5.4 GHz
> −127 dBm ±0.85 dB ±1.0 dB -
> −100 dBm ±0.85 dB ±1.0 dB ±1.5 dB
> 0 dBm ±0.50 dB ±0.7 dB ±1.0 dB
Temperature
stability
(dB/°C)
±0.005 ±0.01 ±0.02
2030 with Option 003: ±1.2 dB for output levels greater than
−127 dBm.
VSWR For output levels less than 0 dBm:
Less than 1.25:1 to 2.2 GHz (return loss greater than 19.1 dB);
Less than 1.4:1 to 2.7 GHz (return loss greater than 15.6 dB);
Less than 1.5: 1 to 5.4 GHz (return loss greater than 14 dB).
Output protection An electronic trip protects the generator output against reverse
power of up to 50 W from a source VSWR of up to 5:1.
Output connector 50 Ω nominal, N-type female socket.
