64 Firmware Version 7.2
• Differential Source
Select choice of WAAS/EGNOS,
Satellite (TerraStar®), Glide, RTK, or
RTK External differential sources.
• Wrench button
Pressing the Wrench button opens
different settings screens, depending
on the differential source selected.
• Age of Differential
Displays the elapsed time since
reception of last differential correction
signal. The Age of Differential button is
only functional when GPS is
connected.
• StableLoc checkbox
StableLoc maintains accurate steering
– even when your correction signal is temporarily lost – by seamlessly transitioning to the next available
signal source. When the signal is restored, the system will then transition back to the higher accuracy
source, eliminating position jumps.
• StableLoc Wrench Icon
Opens StableLoc “WAAS/EGNOS” fallback enable/disable setting.This allow SBAS correction to be used
as fallback for StableLoc. Setting is enabled by default. Disable setting if region does not provide SBAS
correction source (such as WAAS/EGNOS).
• StableLoc Error Limit (RTK & TerraStar only)
When using StableLoc, select the error limit at which the system will no longer allow steering. If your error
limit is “4 in (10 cm)” and the system accuracy reaches that limit, steering will no longer be allowed until the
error decreases. If set to “none” accuracy of the differential source will not affect the ability to autosteer.
• Reset to Defaults
Press the Reset to Defaults button to restore receiver settings to the factory default. This will remove all
custom settings.
• NMEA Talker
This button disables the GLONASS prefix in the NMEA messages. If using the GPS receiver with legacy
displays or a device that does not support GLONASS messages, uncheck the box.
Note: If using OmniSTAR, see “OmniSTAR Settings” on page 78.
Upgrade
Receiver
Features
Reset to
Defaults
Age of Differential
Differential Source
StableLoc
GPS Settings
StableLoc Error Limit
RTK
General
Port A (Connected)
Port B
2 in
4 in
6 in
8 in
12 in
None
NMEA Talker
60
