3.9. Commander Control Components
3.9.1 Main Control Box
Figure 56. Main Control Box
WARNING
Pushing the E-STOP button
will turn OFF all outputs from
the PLC. It does NOT shut
off power into either Control
Box. The Power ON lamp will
remain lit on the Main Control
front panel.
EMERGENCY
STOP
BUTTON
(E-STOP)
POWER ON
LAMP
MAIN
DISCONNECT
(CE ONLY)
ELECTRICAL
SCHEMATICS
BLOWER
MOTOR
STARTERS
CABLE ENTRY PORTS
