AGI D1660 - Start Dryer - Main; Start Dryer Overview

7713395 R2 83
4.6. Start Dryer - Main
4.6.1 Start Dryer Overview
The Start Dryer main screen is used for:
• Setting necessary drying parameters and then activating either BATCH or AUTO mode.
• Refer to the following sections (designated A, B and C) to correctly set parameters for the required drying
mode:
– Section – A. Crop and Cooling Setup on page 84: Change, add, or edit crops and setup cooling tiers. The
current crop and cooling tier layout are shown in the upper-left area of the screen, below the NECO
logo.
– Section – B. Enable or Disable Blowers and Burners on page 87: Set enable or disable for blower(s) and
burner(s) for either BATCH MODE or AUTO MODE.
– Section – C. Set Burner Temperature on page 88: Set burner temperature setpoints for either BATCH
MODE or AUTO MODE.
CONTINUOUS MIXED-FLOW GRAIN DRYER WITH COMMANDER CONTROL SYSTEM 4. OPERATION
