Agilent Technologies 1200 series - Site Requirements

24 Agilent 1200 Series Autosampler Reference Manual
1 Installing the Autosampler
Figure 4 Recommended Stack Configuration for a thermostatted ALS (Rear View)
LAN
Link Config
Init Mode
HP IBHP-IB Address
LAN to LC
ChemStation
Analog signal
to recorder
Remote
cable
CAN bus cable
Autosampler -
Thermostat cable
Analog signal
to recorder
