© Agilent Technologies 2001–2003 Agilent 3070 System Installation Manual (MS Windows Version) 2-63
Chapter 2: MS Windows System Installation Reference: Installing Drivers and Configuring LAN Ports
5 In Explore, navigate to the Setup file and
double-click Setup.
6 At Welcome to the InstallShield Wizard for Intel PRO
Intelligent Installer, click Next.
7 At License Agreement, click I accept the terms in the
license agreement. Then click Next.
8 At Setup Type, select Typical. Then click Next.
9 At Ready to Install the Program, click Install.
10 At Wizard Completed, click Finish.
11 At Results, click OK.
12 Click X in the right corner to close the window.
13 Click Start > Shutdown > Restart > OK.
14 Login as Administrator and click OK.
NOTE
The following three steps are only necessary if the
SBC has the newer firmware.
15 Click Start > Settings > Network and Dial-up
Connectons.
16 Under Driver name for Local Area Connection is:,
select Intel (R) PRO/100 VE Network Connection.
17 Under Driver name for Local Area Connection 2 is:,
select Intel (R) PRO/100 M Netowrk Connection 2.
Installing the Secondary LAN Driver
1 Right-click My Computer.
2 Click Manage > Device Manager.
3 Under Other Devices, click Ethernet Controller >
Properties > Reinstall Driver.
4 Under Welcome to the Upgrade Device Driver Wizard,
click Next.
a Under Install Hardware Device Drivers, select
Display a list of hte known drivers for this device so
that I can choose a specific driver and click Next.
b Under Hardware Type, select Network Adapters
and click Next.
c Under Select Network Adapter Manufacturer:,
select Intel.
d Under Network Adapter:, select Intel 8255x-based
PCI Ethernet Adapter (10/100) (Intel) and click Next.
e Under Update Driver Warning, click Yes.
f Under Start Device Driver Installation, click Next.
5 Under Completing the Upgrade Device Driver Wizard,
click Finish > Close.
6 Remove the CD from the drive.
7 Click Start > Shutdown > Restart > OK.
8 Login as Administrator and click OK.
