© Agilent Technologies 2001–2003 Agilent 3070 System Installation Manual (MS Windows Version) 1-6
Chapter 1: MS Windows System Installation Procedure: Setting Up the KVM and Support Arms
Table 1-2 Install the KVM and support arms
Task Step
1 Remove the two shipping
bolts.
Do this so that the testhead can be rotated. Figure 1-1 on page 1-11 shows the
location of the shipping bolts.
2 If the KVM will be
installed on the left
(non-default) side, follow
the steps for this task.
Otherwise, continue with
Task 3.
CAUTION
✸
Before rotating the testhead, remove all objects including the monitor
and keyboard support arms from the rotational path of the testhead.
During rotation, should the testhead hit anything, damage could result.
CAUTION
✸
Remove the shipping bolts before attempting to rotate the testhead.
Otherwise, damage can result. Shipping bolts can be stored for later use
in the holes used by the testhead pallet shipping brackets.
Remove pod cover:
a If testhead connectors (BNC) are visible over a pod cover, rotate the
testhead about 10 degrees to allow the pod cover to be removed.
Apply PDU power to activate the testhead rotation switch. See Powering
the PDU and Controller on page 1-21.
b Use a T20 Torx driver to remove the pod-cover screws and then remove the
pod cover.
c Remove power to the PDU if connected.
To Next Page
