© Agilent Technologies 2001–2003 Agilent 3070 System Installation Manual (MS Windows Version) 1-12
Chapter 1: MS Windows System Installation Procedure: Setting Up the KVM and Support Arms
Figure 1-2 KVM and support arm detail for the right side of the testhead
Video Monitor
(Flat Panel Display)
Support Arm Tension
Adjustments (Top View)
(1/4-inch hex)
Monitor Arm
on top
Keyboard Arm
on bottom
Keyboard Mouse
Keyboard Tray
Tilt Adjustment
T-piece post inside column
Cables Troughs
Short, Medium, Long
Support Arm
T- piece
Right Pod
Riser under
Monitor Arm
Post Screw Holes
Use top and bottom for 307X or 317X,
middle and bottom for 327X
S
L
L
M
M
