4-32
Printing, Plotting, and Saving Measurement Results
Printing or Plotting the List Values or Operating Parameters
Printing or Plotting the List Values or Operating Parameters
Press and select the information that you want to appear on your hardcopy.
• Choose if you want a tabular listing of the measured data points, and their current
values, to appear on your hardcopy. This list will also include the limit test information, if you have the
limits function activated.
• Choose if you want a tabular listing of the parameters for both
measurement channels to appear on your hardcopy. The parameters include: operating parameters,
marker parameters, and system parameters that relate to the control of peripheral devices.
If You Want a Single Page of Values
1. Choose for a printer or for a plotter peripheral, to create a
hardcopy of the displayed page of listed values.
2. Press to display the next page of listed values. Press to display
the previous page of listed values. Or, you can press or
repeatedly to display a particular page of listed values that you want to appear on your hardcopy. Then
repeat the previous step to create the hardcopy.
3. Repeat the previous two steps until you have created hardcopies for all the desired pages of listed
values.
If you are printing the list of measurement data points, each page contains 30 lines of data. The number of
pages is determined by the number of measurement points that you have selected.
If You Want the Entire List of Values
Choose to print all pages of the listed values.
NOTE If you are printing the list of operating parameters, only the first four pages are printed. The
fifth page, system parameters, is printed by displaying that page and then pressing
.
