6- 51
Calibrating for Increased Measurement Accuracy
Calibrating for Non-Coaxial Devices (ES Analyzers Only)
8. To assign the calibration standards to the various TRL calibration classes, press:
9. Since you previously designated standard #1 for the REFLECT standard, press:
10. Since you previously designated standard #6 for the LINE/MATCH standard, press:
11. Since you previously designated standard #4 for the THRU/LINE standard, press:
12. To complete the specification of class assignments, press:
Label the Classes
NOTE To enter the following label titles, an external keyboard may be used for convenience.
13. Press .
14. Change the label of the "TRL REFLECT" class to "TRLSHORT."
15. Change the label of the "TRL LINE OR MATCH" class to "TRLLINE."
16. Change the label of the "TRL THRU" class to "TRLTHRU."
17. Press .
Label the Calibration Kit
18. Press and create a label up to 8 characters long. For this example, enter "TRL KIT1"
DONE.
19. To save the newly defined kit into nonvolatile memory, press:
NOTE Refer to "Saving Modified Calibration Kits to a Disk" on page 7-65 for information about
saving modified calibration kits, along with calibration data and instrument states, to a disk.
