7- 90
Operating Concepts
Differences between 8753 Network Analyzers
Color display Ye s Yes Yes
Flat panel LCD No Yes Yes
VGA output No Yes No
Delete display (Option 1DT) No Yes No
Tes t s equ en cin g Ye s Yes Yes
Automatic sweep time Ye s Yes Yes
External source capability Ye s Yes Yes
Tuned receiver mode Ye s Yes Yes
Printer/plotter buffer Ye s Yes Yes
Harmonic measurements (Option 002) Ye s Yes Yes
Frequency offset mode (mixer measurements) Ye s Ye s Yes
dc bias to test device
a
a
a
Interfaces: RS-232, parallel, and DIN keyboard Ye s Yes Yes
User-defined preset Ye s Yes Yes
Non-volatile memory (in Kbytes) 512 2000 2000
Dynamic range: 30 kHz 3 GHz 100 dB 100 dB 100 dB
Dynamic range: 3 GHz 6 GHz 110 dB 110 dB 110 dB
Real time clock Ye s Yes Yes
a. For this network analyzer, the feature is dependent on the test set being used.
b. 300 kHz to 3 GHz without Option 006; 30 kHz to 6 GHz, with Option 006.
Table 7-7 Comparing the 8753D/E/ES Option 011 Network Analyzers (Continued)
Feature 8753D
Option 011
8753E
Option 011
8753ES
Option 011
