134 Chapter 5
Replaceable Parts
Replaceable Parts List
Left Side View
Figure 5-19 Left Side View
Table 5-21 Left Side View
Ref.
Desig.
Agilent Part Number Qty. Description
1 E5071-61603 1 FLAT CABLE ASSY
2 E5071-00607 1 PLATE
3 0515-1946 2 SCREW-MACH M3.0 x L6 FL T10
4 0515-0430 2 SCREW-MACH M3.0 x L6 PN T10
5 0515-2146 1 SCREW-MACH M3.0 x L4 FL T10
6 0515-1946 2 SCREW-MACH M3.0 x L6 FL T10
