Chapter 3 53
Adjustment
Required Adjustment after Replacing Assembly
1. Chapter Title
2. Chapter Title 3. Adjustment
4. Chapter Title
5. Chapter Title
Required equipment for OCXO adjustment
Frequency Reference Adjustment
The purpose of this procedure is to adjust the 10 MHz frequency reference on the source
board.
Required equipment for frequency reference adjustment
AUX Input Adjustment
The purpose of this procedure is to adjust the offset error and proportional error of AUX
Input.
Required equipment for the AUX input adjustment
Synthesizer Gain Adjustment
The purpose of this procedure is to adjust 2Bit ATT of RF Path in Synsthesizer for Source.
Required equipment for the synthesizer gain adjustment
None
Description Recommended Model
Frequency Counter Agilent 53181A with Opt. 010 and 124 or Agilent
53131/2A with Opt. 010 and 124
Frequency Standard Agilent 5071A
BNC(m)-BNC(m) Cable, 61 cm Agilent p/n 8120-1839
Description Recommended Model
Frequency Counter Agilent 53181A with Opt. 010 and 124 or Agilent
53131/2A with Opt. 010 and 124
Frequency Standard Agilent 5071A
BNC(m)-BNC(m) Cable, 61 cm Agilent p/n 8120-1839
Description Recommended Model
Function Generator Agilent 33120A or 33250A
Multi Meter Agilent 34401, 34410, 34411 or 3458A
BNC(m)-BNC(m) Cable, 61 cm x 4 ea Agilent p/n 8120-1839
BNC T Adapter x 2ea Common Parts
Banana BNC Common Parts
