Chapter 5 135
Replaceable Parts
Replaceable Parts List
5. Replaceable Parts
Right Side View
Figure 5-20 Right Side View
Table 5-22 Right Side View
Ref.
Desig.
Agilent Part Number Qty. Description
1 E5071-61604 1 FLAT CABLE ASSY
2 1400-0611 2 CLAMP CABLE
3 0515-1946 &
3050-2247
1 SCREW-MACH M3.0 x L6 PN T10
4 0515-2146 1 SCREW-MACH M3.0 x L4 FL T10
5 0515-0430 2 SCREW-MACH M3.0 x L6 PN T10
6 0515-0372 1 SCREW-MACH M3.0 x L8 PN T10
To Next Page
