Required Equipment
Required Equipment
1) Up to 8.5 GHz Options
Table 1-2 lists the recommended equipment for performing maintenance on the E5071C.
Table 1-2 Recommended Test Equipment
Equipment Critical specifications Recommended Model Qty.
Use
*1
Frequency Counter Frequency: 50 MHz to 8.5 GHz
Accuracy: < 2.5 ppm
Agilent 53181A with
Opt.010 & 124
1 P,A
Frequency Standard Frequency: 10 MHz, Time Base
Error: ≤ ± 1× 10
–10
/year
Agilent 5071A 1 A
Power Meter No Substitute
Agilent E4419A/B
*2
1 P,A
Power Sensor No Substitute Agilent 8482A 1 P
Power Sensor No Substitute Agilent E9304A with Opt.
H18
1 P,A
Function Generator Agilent 33120A 1 P,A
Multimeter Agilent 3458A or 34401A 1 P,A
Dynamic Accuracy
Test Kit
No substitute Agilent Z5623A with Opt.
H01
1 P
Calibration Kit No Substitute Agilent 85032F 1 P,A ,T
Short Type-N(m) part of Agilent
85032F/54D/33E/50D with
Type-N adapter
1 P,T
Short Type-N(f) Agilent p/n 85032-60009 1 P,T
Short Type-N(m) Agilent p/n 85032-60008 4 P,T
Load Type-N(m) part of Agilent
85032F/54D/33E/50D with
Type-N adapter
2 P
Fixed attenuator (6
dB)
50 Ω, N(m)-N(f), VSWR ≤ 1.015 Agilent 8491A w/Opt.006
and H60
1 P
Fixed attenuator (10
dB)
50 Ω, N(m)-N(f) Agilent 8491A/B/C 1 T
Handler I/O Test Kit No substitute Agilent p/n E5070-65001 1 T
