52 Chapter 3
Adjustment
Required Adjustment after Replacing Assembly
Writing ID
This item writes the serial number and the option structure into the E5071C.
Required equipment for the writing ID
None
OCXO Adjustment
The purpose of this procedure is to adjust the 10 MHz OCXO.
Table 3-2 Over 8.5 GHz Options
Replaced Assembly Adjustment Item
Writing ID
OCXO
Frequency Reference
AUX Input
Synthesizer Gain
Source Output Power
Receiver IF Range
Receiver Port Characteristics
Receiver Absolute Gain
PCI-DSP Card (PCI/DSP)
√
Reference Oven Board (OCXO)
√
Analogue Base Module (BAS)
√ √
Synthesizer Module (SYN)
√ √ √ √
Receiver Module (RCV)
√ √ √ √
Doubler Module (DBL)
√ √
Distributor Module (DIS)
√ √ √
Imix (IMX)
√ √ √
Front End Module (FEM)
√ √ √
Hark Disk Drive (HDD)
√
To Next Page
