180 Chapter 6
Replacement Procedure
Hard Disk Drive Replacement Option 019
Hard Disk Drive Replacement Option 019
Tools Required
• TORX screwdriver, T10
• Torque screwdriver, TORX T10 (set to 0.50 N-m / 4.4 lb-in)
Removal procedure
Refer to Figure 6-9 for this procedure.
Step 1. Remove the outer cover as described in “Outer Cover Removal” on page 167.
Step 2. Disconnect the two cables (item 1).
Step 3. Remove the four TORX T10 screws (item 2) fastening the hard disk assembly.
Step 4. Remove the four TORX T10 screws (item 3) fastening the hard disk bracket.
Step 5. Remove the hard disk drive (item 4) from the connector board.
WARNING From the volume label CN925, user recovery function is not prepared. It is required
to inform this change to user before replacing the hard disk drive.
