232 Chapter 6
Replacement Procedure
Inverter Board Replacement
Inverter Board Replacement
Tools Required
• TORX screwdriver, T8, T10, T15, and T20
• Flat edge screwdriver
Removal Procedure
Refer to Figure 6-36 for this procedure.
Step 1. Remove the outer cover as described in “Outer Cover Removal” on page 167.
Step 2. Remove the front panel as described in “Front Panel Removal” on page 168.
Step 3. Remove the front panel cover as described in “Front Panel Cover Removal” on page 230.
Step 4. Disconnect the three cables (item 1) connected front panel keyboard.
NOTE Be careful to remove the cables (item 1), and not apply any scratches on the cables.
Step 5. Remove the two TORX T15 screws (item 2) fastening the inverter assembly.
Step 6. Disconnect the two cables (item 3) connected inverter assembly.
Step 7. Remove the two TORX T8 screws (item 4) fastening the inverter to the bracket and lift it
(item 5).
To Next Page
