194 Chapter 6

Replacement Procedure

PCI DSP Card and GPIB Card Replacement (A51)

Figure 6-16 PCI DSP Card and GPIB Card Removal

Replacement Procedure

Step 1. Replace the PCI DSP card and GPIB card by inverse procedure of removal.

NOTE Fasten the 5/8 inch nuts (item 8) using an open-end torque wrench.
