292 Appendix D
Power Requirement
Preparation for Power Supply
Preparation for Power Supply
Before turning on power to the equipment, be sure to verify the following:
Power Requirements
The E5071C requires the following power source:
Verification and Connection of Power Cable
The three-wire power cable attached to the E5071C has one wire serving as a ground.
Using this power cable allows the E5071C to be grounded, thereby protecting you against
electrical shock from the power outlet.
Step 1. Confirm that the power cable is not damanged.
WARNING NEVER use a power cable showing any sign of damage. Faulty cables can cause
electrical shock.
Step 2. Use the supplied cable to connect between the power cable receptacle on the rear panel of
the E5071C and a three-wire power outlet with the grounding prong firmly connected in
the ground slot.
WARNING Use the supplied power cable with grounding wire to securely ground the E5071C.
Power cord list, 16000-99101 shows the power cable options.
Blown Fuses
If the fuse appears to have blown during operation, this instrument may be subject to
failure and must be repaired. For any assistance, contact Agilent Technologies Customer
contact centre listed at the end of this guide.
This product uses the following fuse type:
Up to 8.5 GHz Options: UL/CSA Type, Slow-Blo, 6.3 A-250 Vac.
Over 8.5 GHz Options: UL/CSA Type, Slow-Blo, 10A-250 Vac.
WARNING DO NOT replace the fuse yourself; doing this may expose you to electrical shock.
Requirements
Vo l t a g e 100 - 240 VAC ± 10% (Vpeak >= 120 V)
Frequency 47 to 63 Hz
Maximum power consumption 350 VA
