140 Chapter 5
Replaceable Parts
Replaceable Parts List
Table 5-25 Hard Disk Drive Assembly
Ref.
Desig.
Agilent Part Number Qty. Description
1
E5071-823xx
*1
1 HDD INSTALLED (Service Center Only)
2 E5070-66636 1 CONNECTOR BD PCA
3 E5071-01222 1 HDD BRACKET
4 0515-0430 2 SCREW-MACH M3.0 x L6 PN T10
5 0515-0374 4 SCREW-MACH M3.0 x L10 PN T10
6 0515-2028 2 SCREW-MACH M2.5 x L6 FL T8
7 E5070-01255 1 BRACKET HDD
8 0515-2146 4 SCREW-MACH M3.0 x L4 FL T10
9 E5071-01220 1 HDD BRACKET
10 E5071-01223 1 HDD BRACKET
11 E5071-01201 1 HDD BRACKET
12 0515-0430 4 SCREW-MACH M3.0 x L6 PN T10
13 E5070-25061 1 TM SHEET 0.5T
*1.The number indicated by "xx" in the part number of each HDD, 01 for the first revision is incremented by 1 each
time a revision is made. Check the Find-A-Parts site for the latest part-number.
To Next Page
