Appendix B 281
System Recovery
Initial Registration of E5071C
B. System Recovery
Figure B-8 Agilent Recovery Image Setup Screen(1/1)
Step 7. A progress bar appears (Figure B-9) indicating the progress of the Recovery Image setup.
The complete process takes less than 5 minutes to finish.
Figure B-9 Agilent Recovery Image Setup Screen(1/2)
Step 8. A message dialog box appears after the completion of the Recovery Image Setup
procedure. The dialog box disappears automatically after a few seconds.
Step 9. E5071C firmware is executed, then the measurement display appears.
NOTE If the touch screen does not work after Initial Registration, refer to “Reconfiguring Touch
Panel Settings” on page 281.
Reconfiguring Touch Panel Settings
Step 1. In E5071C, right click My Computer.
Step 2. Select Properties. The System Properties dialog box appears.
Step 3. Select Hardware tab.
Step 4. Click Device Manager. The Device Manager dialog box appears.
Step 5. Select Ports (COM & LPT).
Step 6. Check if two Communication Port (COM1) are displayed.
To Next Page
