Operation Example
Assume that you are going to generate an I/Q modulated
signal with 1 GHz carrier frequency, amplitude of –10 dBm
Refer to the following procedures to configure and generate
an I/Q modulated signal:
1 Connecting the external I/Q source to the BNC I and Q
connectors on the rear panel of the signal generator
2 Pressing presets the signal generator
3 Pressing > 1 > GHz sets the CW frequency to 1 GHz
4 Pressing > –10 > dBm
sets the CW amplitude to –10 dBm
5 Pressing enters the I/Q modulation submenu
6 Pressing I/Q On/Off enables I/Q modulation
7 Pressing enables I/Q modulated signal output
Preset
Frequency
Amplitude
I/Q
RF
On/Off
To Next Page
