Photoresistor Settings: Set the minimum and maximum photo-resistor
value based on the current actual photo-resistor value detected to control
the on-off of the LED light. You set the maximum photo-resistor value for
the IR LED to be turned on and the minimum value for it to be turned off.
While the default Min/Max photo-resistor value is 1500 and 1600
respectively.
Threshold: Refers to the current light intensity indicated by the
photo-resistor value. The higher photo-resistor values correspond
conversely to the lower light intensity and vice versa ( darker). The default
photo-resistor value (Threshhold) is 1132, however you can click Read
several times in order to obtain the actual photo-resistor value in a specific
environment ( the value fluctuation is about 5), and the value is what you
based on to configure the minimum and maximum photo-resistor values.
5.2.3. LED Display Status
LED display adjustment is used to display the light changes of the device in six
states - normal(idle), offline, calling, talking and receiving a call. and the user
can also judge the current mode of the device through the state of the led.
5.2.3.1. Setup LED Display from Website
To do so, you can follow the following process.
1. Click Intercom - LED Setting.
2. Adjust the Color on and blink mode as you need.
3. Click Submit tab to save.
