5.9.3.2. MJPEG Codecs
To configure the parameters, please do as follows:
1. Click Intercom - RTSP to find MJPEG Video Parameters.
2. Set up video parameters according to your need.
3. Click Submit tab for validation and Cancel tab for cancellation.
Parameters Set-up:
Video Resolution: Select video resolutions among seven option: “QCIF”,
“QVGA”,”CIF”,”VGA”,”4CIF”,”720P,””1080P”. The default video resolution
is “720P.
Video Framerate: “30fps” is the video frame rate by default.
Video Quality: Video bitrate, the default is 90.
Note:
Video framerate and quality of MJPEG is fixed.
5.9.4. ONVIF
The ONVIF specification describes the network video model, interface, data
type, and data interaction mode. And reuse some existing standards, such as
WS series standards. The goal of the ONVIF specification is to implement a
network video framework protocol, so that network video products (including
To Next Page
