3. Click Submit tab to save.
Parameters set-up:
HTTP URL format:
http://PhoneIP/fcgi/do?action=LedAction&State=1&Color=1&Mode=2500
Status: 1=Idle; 2=OffLine; 3=Calling; 4=Talking; 5=Receiving; Color:
1=Green; 2=Blue; 3=Red; Mode: 0=Always On; 1=Always Off;
500/1000/1500/2000/25000/3000
Note:
1.The Status and Color off item can not be changed.
2.The LED of upgrading mode can not be adjusted.
5.2.4. LED Setting on Card Reader Area
You can enable or disable the LED lighting on the card reader area as needed
on the web interface. Meanwhile, If you prefer not to have the LED light on the
card reader area stay on, you can also set the timing for the exact time span
during which the LED light can be enabled in order to reduce the electrical
power consumption etc.,
To do so , you can follow the following process.
1. Click Intercom - LED Setting to find LED Control.
2. Set the parameter and press Submit button to validate the setting.
Parameters Set-up:
