MPLS and RSVP
7210 SAS M, T, X, R6, Mxp MPLS Configuration Guide Page 177
interface
Syntax interface [ip-int-name | ip-address] [label-map label]
interface [ip-int-name | ip-address]
Context show>router>mpls
Description This command displays MPLS interface information.
Parameters ip-int-name — The name of the network IP interface. An interface name cannot be in the form of an
IP address. If the string contains special characters (#, $, spaces, etc.), the entire string must be
enclosed within double quotes.
ip-address — The system or network interface IP address.
label-map label — The MPLS label on which to match.
Values 32 — 1048575
Output MPLS Interface Output Fields — The following table describes MPLS interface output fields.
A:7210SAS# show router mpls interface
===============================================================================
MPLS Interfaces
===============================================================================
Label Description
Interface
The interface name.
Port-id
The port ID displayed in the slot/mda/port format.
Adm
Specifies the administrative state of the interface.
Opr
Specifies the operational state of the interface.
Srlg Groups
Specifies the shared risk link group (SRLG) name(s).
Te-metric
Specifies the traffic engineering metric used on the interface.
Interfaces
The total number of interfaces.
Transmitted
Displays the number of packets and octets transmitted from the inter-
face.
Received
Displays the number of packets and octets received.
In Label
Specifies the ingress label.
In I/F
Specifies the ingress interface.
Out Label
Specifies the egress label.
Out I/F
Specifies the egress interface.
Next Hop
Specifies the next hop IP address for the static LSP.
Type
Specifies whether the label value is statically or dynamically assigned.
