Add Distributed I/O Modules to the Project Chapter 11
14. Drag and drop a Branch
instruction into the first rung.
15. Expand tthe Branch to the right side of the xxxx_Light.
16. Drag and drop another Output Energize element onto
the Branch and name it xxxx_Light (where xxxx is
the suffix of the catalog number of the digital 1734
POINT output module).
17. Right-click the Light and select New
‘xxxx_Light’.
