Component Kits
All kits include the necessary components, ESD wrist strap and hardware (if
required), and thermal grease (if required). Do not reuse any hardware unless
directed to do so.
Description Kit Catalog No. Notes
Printed Circuit Boards
Gate Interface Board SK-G1-GDB1-F8910 Drive requires three kits.
Precharge Board SK-G9-PRE1-V480 For AC input only
(2)
1336-PB-SP22C For DC input only
(3)
Power Interface Board SK-G9-GDB1-D875 875 A
Main Control Board SK-G9-VMCB1-D0 115V I/O
SK-G9-VMCB1-C0 24V I/O
T-Comm Board SK-G9-TCOMM
Switch Mode Power Supply Board SK-G9-PWRS1-D0
DC Bus Filter Board 2364-SPP02A
Fans and Main Fan Circuit Components
Converter Heatsink Fan SK-G1-FAN1-F810 Includes fan and fan enclosure
Inverter Heatsink Fan SK-G1-FAN1-F10 Includes fan and fan enclosure
Capacitor Fan SK-G1-FAN2-F8910
Power Module Sub-assemblies
Inverter Power Module (IGBT) SK-G1-QOUT1-F910 Includes:
• One IGBT module
• One Gate Interface Board
• Gate Interconnect Harness
• Six Flexible Capacitor Busbars
• Three Snubber Capacitors
• One Tie Down Capacitor Mount
Drive requires three kits.
Converter Power Module (SCR) SK-G1-SCR1-F10 For AC input only.
(2)
Kit includes two SCR Modules.
Drive requires three kits.
We recommend replacing all three phases
(three kits) at the same time.
SCR Snubber Kit SK-G1-SCRSNUBRB AC input requires three kits.
DC input requires one kit.
DC Link Choke SK-G1-DCCHOKE1-F10 For AC input only
(2)
Miscellaneous
Balancing Resistor Kit SK-G1-RB1-F910 (Replaces
1336-RLOAD-SP3A)
(1)
AC and DC Input (includes DC+ bus bar and
resistor assembly).
Bus Capacitor Kit SK-G1-BUSCAP1-F10 Includes one Capacitor.
Drive requires 26 kits.
Capacitor Bus Finger Kit SK-G1-FLXBUS1 Included with the kit for Inverter Power
Module (IGBT).
Can be ordered separately without Inverter
Power Module (IGBT) if needed.
Includes busbars for one phase:
• Three positive Flexible Capacitor Busbars
• Three negative Flexible Capacitor Busbars
Drive requires three kits.
Current Transducer SK-G1-CT1-F910 Includes one Transducer.
Drive requires three kits.
MOV Surge Suppressor SK-G1-MOV1-F10 For AC input only
(2)
Power Supply, 24V SK-G9-PWRS24 For Current Transducers (CTs)
Thermal Sensor Kit SK-G1-THM1-F10 Includes:
• Main Control Panel Thermal Sensor
• Heatsink Thermal Sensor
Transformer, 1000 VA SK-G9-XFMR1-F10 For AC input only.
(4)
Includes:
• One Transformer
• Three fuses
(5)
Transformer Fuses
(5)
SK-G9-FUSE1-F10 For AC input only
(4)
