Rockwell Automation Publication 20B-IN026C-EN-P - October 2015 11
Preface
See the master parts list for the most up-to-date information:
http://www.ab.com/support/abdrives/powerflex70/PF7ReleasedParts.pdf
Recommended Tools
The following list of tools is provided for your reference to disassemble and
reassemble the drive and components. This list may not include all tools for your
situation. Not all tools are needed for some components. See specific sections for
details.
Enclosure Options
Converter Gasket Kit SK-G1-GASKET2-F10 For AC input only
(2)
Inverter Gasket Kit SK-G1-GASKET1-F10 For DC input only
(3)
(1) This kits was issued to correct a potential anomaly for frame 10 PowerFlex 700 AC drives. See Product Safety Advisory #2014-06-002
for more information.
(2) AC input applies to PowerFlex 700 catalog numbers beginning with 20BC875 or 20BD875.
(3) DC input applies to PowerFlex 700 catalog numbers beginning with 20BH875 or 20BJ875.
(4) Transformer and transformer fuses apply to AC input PowerFlex 700 catalog numbers beginning with 20BC875A or 20BD875A (IP20,
NEMA/UL Type 1 only).
(5) Fuses included with order are two 6 A fuses and one 9 A fuse.
See the instruction sheet included with each component kit for discarding
or returning replaced components.
If discarding, be sure to discard according to local, state, and federal
regulations.
Description Kit Catalog No. Notes
Description
Torque wrench (metered in N•m or lb•in)
Volt ohm meter
Torque seal or colored marker
Screwdrivers (standard, Phillips, torx
– various sizes)
Magnetic screwdriver, long
Socket set, metric
Cylindrical pick-up magnet
Pliers, regular and needle-nose
Wire cutters
Isopropyl alcohol and applicator cloth
Nylon tie wraps
3- or 4-inch paint roller with short nap or 3- or 4-inch putty knife (for applying thermal grease)
Pencil
