66 Rockwell Automation Publication 20B-IN026C-EN-P - October 2015
Chapter 3 Inverter Assembly Component Replacement Procedures
Install Components
1. For the Main Control Panel thermal sensor, apply a thin layer of supplied
thermal grease to the metal side of the new Thermal Sensor and install it
with supplied screw with star washer toward the panel. Torque screw to 1.7
N•m
(15 lb•in).
2. For the three Gate Interface Boards, carefully route wires and connect to J8
on each Gate Interface Board. Be sure that the J8 connectors go to the
correct IGBT. See page 60
for connector locations.
3. Reconnect the other end of this wiring harness at the J6 connector on the
Power Interface Board. See page 42
for connector locations.
4. Reassemble remaining components in reverse order.
5. Replace all safety shields and enclosure covers before applying power to the
drive.
