Rockwell Automation Publication 20B-IN026C-EN-P - October 2015 89
Converter Assembly Component Replacement Procedures Chapter 4
6. Unplug the wiring harness at the J6 connector on the Power Interface
Board on the Inverter. See page 45
for connector locations.
Install Components
1. Use isopropyl alcohol to clean the surface where the new Thermal Sensor
will be installed.
2. Apply a thin layer of supplied thermal grease to the metal side of the new
Thermal Sensor and install it with supplied screw with star washer.
3. Torque screw to 0.6 N•m
(6 lb•in).
4. Reconnect the wiring harness to the J6 connector on the Power Interface
Board on the Inverter. See page 45
for connector locations.
5. Reassemble remaining components in reverse order.
6. Replace all safety shields and enclosure covers before applying power to the
drive.
