214 Explicit Messages
Read Safety
Input Normal
Flag
Read Reads the normal
flag status of the
number (1…16)
specified by the
Instance ID.
0E hex 3D hex 01 to 10
hex
04 hex
—
1 byte
00 hex: error
01 hex: normal
Read Safety
Input Error
Information
Cause
Read Reads the cause for
the normal flag of
the number (1…16)
specified by the
Instance ID being off
(error).
0E hex 3E hex 01 to 10
hex
6E hex
—
1 byte
00 hex: no error
01 hex: invalid
configuration
02 hex: test signal
error
03 hex: internal
circuit error
04 hex: discrepancy
error
05 hex: error in
other channel of
dual channels
Read AND of
Safety Input
Normal Flags
Read Reads the cause for
the normal flag of
the number (1…16)
specified by the
Instance ID being off
(error).
0E hex 3E hex 01 hex 05 hex
—
1 byte
00 hex: error
01 hex: all normal
Read OR of
Monitor
Status of
Input Total
On Times or
Contact
Operation
Counters
Read Reads the logical OR
of the monitor status
of the total on time
or contact operation
counter for all inputs
1…16.
0E hex 01 hex 72 hex
—
1 byte
00 hex: all in range
01 hex: input out of
range (over monitor
value)
Setting and Monitoring Safety Input Terminals
Explicit
Message
Service Function
Command
Response
Service
Code
Class
ID
Instance
ID
Attribute
ID
Data Size
