216 Explicit Messages
Read
Monitor
Status of
Output Total
On Time or
Contact
Operation
Counter
Read Reads the monitor
status of the total on
time or contact
operation counter for
the output (1…8)
specified by the
Instance ID.
0E hex 3B
hex
01…08
hex
67 hex
—
1 byte
00 hex: in range
01 hex: out of range
(over monitor value)
Read Safety
Output
Normal Flag
Read Reads the normal flag
status of the number
(1…8) specified by the
Instance ID.
0E hex 3B
hex
01…08
hex
05 hex
—
1 byte
00 hex: error
01 hex: normal
Read Safety
Output Error
Information
Cause
Read Reads the cause for the
normal flag of the
number (1…8)
specified by the
Instance ID being off
(error).
0E hex 3B
hex
01…08
hex
6E hex
—
1 byte
00 hex: no error
01 hex: invalid
configuration
02 hex: overcurrent
detection
03 hex: short-circuit
detection
04 hex: high constant
error
05 hex: error in either
of dual channels
06 hex: internal relay
circuit error
07 hex: relay error
08 hex: data error
between dual channel
outputs
09 hex: detection of
short-circuit between
wires
Read AND of
Safety
Output
Normal Flags
Read Reads the cause for the
normal flag of the
number (1…8)
specified by the
Instance ID being off
(error).
0E hex 3C
hex
01 hex 05 hex
—
1 byte
00 hex: error
01 hex: all normal
Read OR of
Monitor
Status of
Output Total
On Times or
Contact
Operation
Counters
Read Reads the logical OR of
the monitor status of
the total on time or
contact operation
counter for all outputs
1…8.
0E hex 3C
hex
01 hex 72 hex
—
1 byte
00 hex: all in range
01 hex: input out of
range (over monitor
value)
Setting and Monitoring Safety Output Terminals
Explicit
Message
Service Function
Command
Response
Service
Code
Class
ID
Instance
ID
Attribute
ID
Data Size
