274 Rockwell Automation Publication 1560F-UM001A-EN-P - June 2019
Appendix G Using DeviceLogix
Table 73 - Bit Output Mapping
Analog Inputs
Available analog inputs to the DeviceLogix program are all 32-bit integers and
include the data points shown in Ta ble 74
.
Table 74 - Analog Input Data Points
The function of the expansion port inputs depends on the card installed in the
given port. Ta b le 75
shows how the analog inputs are mapped for each card
type.
Table 75 - Expansion Card Input Mapping
Bit
O
u
t
p
uts
Name
D
es
cript
i
o
n
(11) Hardware Boolean Outputs
Aux 1, Aux2 Auxiliary Relays available on the control board.
(1)
?
(1) The Auxiliary Relays must be programmed to “Device Logix” to allow the DeviceLogix program to control each specific relay. For
example, if you want to control Aux 1 on the control module you must configure “Aux1 Config” (parameter #172) to “Device
Logix”. Similarly, to control Aux 1 in a Digital I/O (150-SM4) expansion card you must configure “Aux 1 Config” (parameter #6 in
the expansion card) to “Device Logix”.
PX Aux1 – PX Aux3
Auxiliary Relays #1 - #3 available on the Digital I/O
(150-SM4) Expansion Card
(1)
(7) Network Boolean Outputs
Coast
Start
Stop
CLR Fault
Emergency Run
Motor Heater
These outputs can be used to control the controller in the
same way a PLC can control the controller. See Table 51 on
page 141 for a definition of these control bits.
Analog Inputs Name Description
(22) Network Analog Inputs
Volt PP Ave Average Phase to Phase Voltage (Param #1 - Volts)
I Ave Average Current (Param #5 – Amps)
Torque Average Torque (Param #9 - %)
Real Power Total Real Power (Param #10 – kWatts)
Power Factor Average Power Factor (Param #17 – in hundredths)
Volt PN Ave Average Phase to Neutral Voltage (Param #265 – Volts)
Reactive Power Total Reactive Power (Param #277 – kWatts)
Apparent Power Total Apparent Power (Param #286 – kWatts)
DLX In 1, DLX In 2 DLX General-purpose Input parameters (Param #335, #336)
DLX DL1 – DLX DL6 DLX Datalink Input Parameters (Param #337-342)
PX In 1 – PX In 2 Analog inputs from the expansion cards – See Tab le 75
Bit Input
Digital I/O
(150-SM4)
Analog I/O (150-SM3) PTC / Grd Fault (150-SM2)
Parameter Config
(150-SM6)
PX In 1 None (always 0) Analog In #1 (Param X.6) Ground Current (Param #11) None (always 0)
PX In 2 None (always 0) Analog In #2 (Param X.16) None (always 0) None (always 0)
