50 Rockwell Automation Publication 1560F-UM001A-EN-P - June 2019
Chapter 2 Installation
Unpacking and Inspection
After unpacking the material, check the item(s) received against the bill of lading
to ensure that the nameplate description of each item agrees with the material
ordered. Inspect the equipment for physical damage, as stated in the Rockwell
Automation Conditions of Sale.
Remove all packing material, wedges, or braces from within the controller.
Operate the contactors and relays manually to ensure that they operate freely.
Store the equipment in a clean, dry place if it will not be installed immediately
after unpacking. The storage temperature must be between -20…75 °C
(-4…167 °F) with a maximum humidity of 95%, non-condensing, to guard
against damage to temperature sensitive components in the controller.
General Precautions
In addition to the precautions listed throughout this manual, the following
statements, which are general to the system, must be read and understood.
Transportation and
Handling
The controller must be transported on a pallet or via use of the lifting angles
supplied as part of all 2.3 m (90 in.) high cabinets or frame units.
Round rollers can be used to assist in moving the controller to the installation
site. Once at the final site, the pipe rolling technique can be used to place the
cabinet in the desired position.
ATTENTION: The controller contains ESD (electrostatic discharge) sensitive
parts and assemblies. Static control precautions are required when installing
testing, servicing, or repairing the assembly. Component damage may result if
ESD control procedures are not followed. If you are not familiar with static
control procedures, refer to applicable ESD protection handbooks.
ATTENTION: An incorrectly applied or installed controller can damage
components or reduce product life. Wiring or application errors, such as
undersizing the motor, incorrect or inadequate AC supply, or excessive ambient
temperatures, may result in malfunction of the system.
ATTENTION: Only personnel familiar with the controller and associated
machinery should plan or implement the installation, start-up, and subsequent
maintenance of the system. Failure to do this may result in personal injury and/
or equipment damage.
ATTENTION: Ensure that the load rating of the lifting device is sufficient to
safely raise the controller sections. Failure to do so may result in severe injury
and/or equipment damage. Refer to the packing slip enclosed with shipment
for shipping weights.
